HANA are most reliable and economical injectors
Whenever you consider choose of gas injectors for LPG, CNG, LNG or Hydrogen appliances you should think carefully about quality, reliability and price.
Then the choice is one!
Not sure which HANA injector you need?
Compare HANA injector color codes — Blue, Blue A+, Green, Red and Gold — and match the right model to your engine, voltage and pressure requirements.
HANA injector selection guideLong Life Span
Warranty for HANA injectors cover around 500 milion cycles (200.000km).
Excellent Reliability
Quality of manufacture and the best used materials provide precise operation for a liftime.
Low Noise Level
HANA injectors provide very low noise level, so you can't say the difference compare to engine noise.
High Resistance
Vibration and Heat resistance allow to work HANAs in hard conditions just attached to the engine.
OEM Applications
Precise dimensions of injectors let them to be installed directly on manifold, in place of petrol injectors.
Longest on the Market
HANA injectors are over 10 years on the worldwide markets which is the best proof of their quality.
Featured Injectors
HANA H2001 Injectors
HANA H2002 Rail Injectors
HANA H2100 Injectors
HANA H2200 Injectors
Injectors comparison chart
| Model | Picture | Type | Flow rate | Resist. | Volt. | Pressure | Time | Current | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Work | Max | Open | Close | Hold | Pick | ||||||
| H2001 | | Blue (A+) | 130 L/min | 1.3Ω | 12V | 1.2 bar | 4.0 bar | 2.8ms | 1.2ms | 2A | 4A |
| H2002 | | Blue (A+) | 130 L/min | 1.3Ω | 12V | 1.2 bar | 4.0 bar | 2.8ms | 1.2ms | 2A | 4A |
| H2100 | | Green (A) | 224 L/min | 1.3Ω | 12V | 1.0 bar | 5.0 bar | 2.9ms | 1.2ms | 2A | 6A |
| Red (B) | 200 L/min | 2.8ms | |||||||||
| Green (A) | 584 L/min | 1Ω | 24V | 5.0 bar | 8.0 bar | 1.54ms | 1.2ms | 2.5A | 7.5A | ||
| H2200 | | Green (A) | 437 L/min | 1Ω | 24V | 6.0 bar | 12 bar | 1.64ms | 0.8ms | 2.5A | 7.5A |
| H2300 | Green (A) | 437 L/min | 1Ω | 12V | 7.0 bar | 12 bar | 1.56ms | 1.3ms | 2A | 4A | |
Injectors accessories
HANA Distribution Rail
HANA Rail
HANA Injector Nozzles
About Us
We are distributor of all range of HANA injectors. Please contact us if you need any technical information, support or if you want to buy high end HANA injectors with accessories.
